If both sides of the connector or its end-face are different, we call it hybrid patch cord. According to the transmission medium, it divides to Single Mode and Multi Mode Fiber Optic Patch Cord; According to the connector structure type, it divides FC, SC, MU, D4, E2000, LC etc.; According to the polished ceramic end-face, it divides to PC, UPC and APC.
Singlemode optical fibre is characterised by its narrow modal dispersion (8.3 to 10 micron diameter); better retaining fidelity of light pulses and exhibiting higher bandwidth than multimode. As a result, singlemode fibre is ideal for long distance applications.
Singlemode patch cables are available with LC, SC, ST, FC, APC/LC, APC/SC, and APC/FC standard connector types. Standard lengths are 1, 2, 3, 5, 7, 10, 15 & 20 meters. Fiber options include standard singlemode and bend insensitive fiber options with microboot.Other lengths and connector types are also available.
Specifications
Parameters | Unit | Values |
Fiber Mode | - | OS2 SMF 9/125μm |
MTP Connector IL | dB | 0.35dB Max(0.15dB Typ.) |
MTP Connector RL | dB | ≥60 |
Attenuation at 1310nm | dB/km | ≤0.32 |
Jacket OD | mm | 3.0 |
Installation Tensile Load | N | 100 |
Cable Jacket | - | LSZH |
Operating Temperature | °C | -10 ~ +70 |
Wavelength | nm | 1310/1550 |
LC Connector IL | dB | ≤0.2 |
LC Connector RL | dB | ≥50 |
Attenuation at 1550nm | dB/km | ≤0.18 |
Fan-Out Diameter | mm | 2.0 |
Long-Term Tensile Load | N | 50 |
Fiber Count |
| 12Fibers |
Storage Temperature | ℃ | -40 ~ +85 |
HTF pay attention to the performance value of each optical fiber jumper. All optical fibers have been specially designed and tested to ensure their excellent performance.
FAQ
Q: What does duplex mean?
A: Duplex means that there is a set of two connectors on each side of the cable. These are duplex cables.
Q: Can I use any fiber patch cable in my network or do I have to order a specific type?
A: Whenever you need to add more fiber to an existing network you must match the mode (single mode or multimode) micron size (62.5/125 or 50/125) and connector type.
Q: What is the maximum distance singlemode fiber can transmit a signal?
A: Singlemode fiber can support gigabit Ethernet up to 10 kilometers in length.
Q: What does plenum mean?
A: Plenum is a rating for cable jackets that ensures that the cables meet installation regulations.
Q: What are the differences between the fiber connectors?
A: SC- Has a molded plug casing with push and pull locking system.LC- Small form factor that resembles an SC connector
